1.Car Model :

for TOYOTA HIACE III Wagon (LH1_, RZH1_) (1989/08 - 2004/08)

HIACE III Wagon (LH1_, RZH1_) 2.5 D-4D 4WD 2KD-FTV 2494 75 102 Bus 01/08 - 04/08

for TOYOTA HILUX II Pickup (RN6_, RN5_, LN6_, YN6_, YN5_, LN5_) (1983/08 - 2005/07)

HILUX II Pickup (RN6_, RN5_, LN6_, YN6_, YN5_, LN5_) 2.5 D-4D 2KD-FTV 2494 65 88 Pickup 01/11 - 05/07

HILUX II Pickup (RN6_, RN5_, LN6_, YN6_, YN5_, LN5_) 2.5 D-4D 4WD 2KD-FTV 2494 75 102 Pickup 01/11 - 05/07

for TOYOTA HIACE IV Bus (LH1_) (1995/08 - /)

HIACE IV Bus (LH1_) 2.5 D-4D 2KD-FTV 2494 65 88 Bus 01/11 - 06/08

HIACE IV Bus (LH1_) 2.5 D-4D 2KD-FTV 2494 75 102 Bus 01/11 - 06/08

HIACE IV Bus (LH1_) 2.5 D-4D 2KD-FTV 2494 70 95 Bus 06/08 - /

HIACE IV Bus (LH1_) 2.5 D-4D 2KD-FTV 2494 86 117 Bus 06/08 - /

for TOYOTA LAND CRUISER 90 (_J9_) (1995/04 - /)

LAND CRUISER 90 (_J9_) 3.0 D-4D (KDJ90, KDJ95, KDJ 125) 1KD-FTV 2982 120 163 Closed Off-Road Vehicle 00/10 - /

for TOYOTA HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) (1989/08 - 2004/08)

HIACE III Box (YH7_, LH6_, LH7_, LH5_, YH5_, YH6_) 2.5 D-4D 4WD 2KD-FTV 2494 65 88 Box 01/08 - 04/08

for TOYOTA HIACE IV Box (LXH1_, RZH1_, LH1_) (1995/08 - /)

HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 2KD-FTV 2494 86 117 Box 06/09 - /

HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 4WD 2KD-FTV 2494 86 117 Box 06/09 - /

HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 4WD 2KD-FTV 2494 75 102 Box 01/11 - 06/08

HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 2KD-FTV 2494 65 88 Box 01/11 - 06/08

HIACE IV Box (LXH1_, RZH1_, LH1_) 2.5 D-4D 2KD-FTV 2494 75 102 Box 01/11 - 06/08

for TOYOTA LAND CRUISER (LJ12_, KDJ12_, KZJ12_, GRJ12_, TRJ12_) (2002/09 - /)

LAND CRUISER (LJ12_, KDJ12_, KZJ12_, GRJ12_, TRJ12_) 3.0 D-4D (KDJ120, KDJ150, KDJ125) 1KD-FTV 2982 120 163 Closed Off-Road Vehicle 03/01 - 10/02

LAND CRUISER (LJ12_, KDJ12_, KZJ12_, GRJ12_, TRJ12_) 3.0 D-4D (KDJ120, KDJ125) 1KD-FTV 2982 122 166 Closed Off-Road Vehicle 04/08 - 10/02

LAND CRUISER (LJ12_, KDJ12_, KZJ12_, GRJ12_, TRJ12_) 3.0 D-4D (KDJ120, KDJ125) 1KD-FTV 2982 127 173 Closed Off-Road Vehicle 02/09 - /

LAND CRUISER (LJ12_, KDJ12_, KZJ12_, GRJ12_, TRJ12_) 3.0 D-4D (KZJ12) 1KZ-TE 2982 92 125 Closed Off-Road Vehicle 02/09 - 10/02

for TOYOTA HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) (2004/11 - /)

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 3.0 D 4WD (KUN26) 1KD-FTV 2982 120 163 Pickup 05/08 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 3.0 D (KUN16) 1KD-FTV 2982 126 171 Pickup 06/10 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 3.0 D (KUN16) 1KD-FTV 2982 120 163 Pickup 05/08 - 06/09

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 2.5 D-4D 4WD 2KD-FTV 2494 106 144 Pickup 07/12 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 2.5 D-4D 2KD-FTV 2494 75 102 Pickup 05/07 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 2.5 D 4WD 2KD-FTV 2494 75 102 Pickup 05/08 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 2.5 D-4D 4WD 2KD-FTV 2494 88 120 Pickup 07/12 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 2.5 D-4D 2KD-FTV 2494 88 120 Pickup 07/12 - /

HILUX III Pickup (TGN1_, GGN2_, LAN_, GGN1_, KUN2_, KUN1_) 3.0 D-4D 4WD 1KD-FTV 2982 126 171 Pickup 07/12 - /

for TOYOTA HIACE IV Box (TRH2_, KDH2_) (2004/08 - /)

HIACE IV Box (TRH2_, KDH2_) 2.5 D-4D 2KD-FTV 2494 70 95 Box 06/09 - /

2.Part NO.

Cargo 114024

CAS CAL40178, CAL40178AS, CAL40178ES, CAL40178GS, CAL40178OS, CAL40178RS, CAL40179AS

Delco DA5389, DRA4279

Denso DAN1347, DAN1349

HB J5112131

HCPARTS JA1796IR

HELLA 8EL011711331, 8EL738211511

KRAUF ALB1796AN, ALB1796GB, ALB1796LK, ALB1796LP, ALB1796MQ, ALB1796UX, ALN1796AN, ALN1796BA,

ALN1796CC, ALN1796DD, ALN1796GB, ALN1796KL,

ALN1796LK, ALN1796LP, ALN1796UX, ALN1796ZD, ALN7796ZD, ALN8796BS, ALN8796GB, ALN8796KL,

ALN8796LK, ALN8796LP, ALN8796NW, ALN8796ZD, ALN9796GB, ALN9796NW

Magneti

Marelli 063731796010, 943317961010, 944390904480, 944390905130, MARC1796, MQA1796, MRA90513

Messmer 210577

Motorherz ALN1796RB, ALN1796WA, ALN8796WA

PMX 89213443

Toyota 270600L010, 270600L020, 270600L021, 270600L022, 270600L02284, 270600L030, 270600L040,

270600L050, 270600L060, 270600L081, 270600L090, 270600L100, 2706030010, 2706030020,

2706030030, 2706030040, 2706030050, 2706030120, 2706030121, 2706030122, 2706030123, 2706030150,

2706030151, 2706030152, 2706030153, 2706030154

Unipoint ALT5123

Valeo 443083

3.Alternator Charge Current [A]:80

4.Voltage [V]:12

5.Number of Ribs:7

6.Model : CFA1029
